Rat Model for Fracture Rattus norvegicus (Rat) Disease model

Bone healing

Add to Cart Distributors
Overview
Properties
  • Prototype SpeciesHuman
  • SourceInduced by surgical method
  • Model Animal StrainsSD rats (SPF class), Male, 6~8W, 200~250g
  • Modeling GroupingRandomly divided into six group: Control group, Model group, Positive drug group and Test drug group
  • Modeling Period6~8 weeks
Share your citation Upload your experimental result Review Leave a message
Loading...

Share a new citation as an author

Upload your experimental result

Review

Please attach serial No. on instruction manual

Contact us

Please fill in the blank.

Name*
Organization
Address
E-mail address*
Telephone
Inquiry*
Verification code* CheckCode
  • Rat Model for Fracture Packages (Simulation)
  • Rat Model for Fracture Packages (Simulation)
  • Rat Model for Fracture Fig: Fracture operation for rat leg
  • DSI797Ra01.jpg Fig: X-ray image of rat fracture legs
  • Rat Model for Fracture Fig. Micro CT imaging for rat femur
  • Certificate ISO9001: 2008, ISO13485: 2003 Registered

Modeling Method

1. After intraperitoneal anesthesia in rats, the left lower limb of rats to wool, disinfection.
2. Make the tibial longitudinal incision in aseptic operation, cut the skin and muscle layer, exposed tibia in lower tibial 1/3 junction, with blades excluding 3mm wide periosteum, revealed subperiosteal bone, the bone rongeur snapped, causing a fracture.
3. Kirschner wire (0.8mm diameter ) were through the knee, straight into the fracture distal fracture, and then the fracture to be reset, the tail close to the top of the knee, and then layer by layer of muscle and skin, do not do fixed.
4. Intraperitoneal injection of penicillin 20U everyday for 3 days.

Model evaluation

1. X-ray photography: 1, 2, 3, 4, 5 weeks after surgery, take the right lower limb X-ray film.
2. X-ray examination for samples: anatomical fracture of the local callus tissue, the visual observation of fracture healing. Remove muscle and other soft tissue, femoral specimen removal of Kirschner wire, the use of X-ray machine shooting positive and lateral film.
3. Micro-CT examination: the specimen placed in the sample holder, adding 40% ethanol solution as a scanning medium, and then the sample holder placed in the 70KPa vacuum box for 20 minutes to ensure that no interference inside and outside the sample bubble. Select the scan parameters to scan the specimen.

Pathological results

1. The callus tissue into the volume fraction of 4% paraformaldehyde fixed 24h, 4~6 weeks after decalcification, embedding, sectioning;
2. HE staining, Masson staining;
3. Immunohistochemical staining (IHC): ALP, BMP, PDGF, VEGF, Runx2, etc..

Cytokines level

Statistical analysis

SPSS software is used for statistical analysis, measurement data to mean ± standard deviation (x ±s), using t test and single factor analysis of variance for group comparison , P<0.05 indicates there was a significant difference, P<0.01 indicates there are very significant differences.
